Features

• Plug & Play installation
• Built in 15KV ESD protection for signals
• RS-422/485 surge & over current protection
• Built in 100 ohm Termination resistor
• Windows, MAC OS, Linux driver support
• Compact Design

Specifications

USB Interface

• Chipset: Silicon Lab CP2102
• USB spec: USB 1.0, 1.1, 2.0
• Connector: USB Type B
• Baud Rates: Full speed 12Mbps

Serial Interface

• Port number: 1
• Port Type: RS-422/485 x 1 Port, auto select
• Connector: 4-pin Terminal Block
• 422/485 Speed 300 bps ~ 230.4 Kbps
• Parity: None, Odd, Even, Mark, Space
• Data Bit: 5, 6, 7, 8
• Stop Bit: 1, 1.5, 2
• RS-232: Rx, Tx, GND, RTS, CTS, DTR, DSR,
• RS-422: Rx+, Rx-, Tx+, Tx-
• RS-485: Data+, Data-
• Receive buffer: 576 Byte
• Transmit buffer: 640 Byte
• Flow Control: X-On / X-Off or Hardware
• Protection: 422/485 Surge & Over Current Protection Built in 15KV ESD protection for all signals
• Termination Built in 100 Ohm Termination resistor Resistor switch On/Off (pull high/low)
• Distance: Up to 1250M

Driver Support

• Windows: 98SE/2000/XP/2003/Server/VISTA/WIN 7/ WIN 8 / WinCE 5.0/6.0
• MAC: OS OSX / OS9
• Linux: 2.4 / 2.6

USB Interface

• Chipset: Silicon Lab CP2102
• USB spec: USB 1.0, 1.1, 2.0
• Connector: USB Type B
• Baud Rates: Full speed 12Mbps

Power

• Input: USB Bus power, DC5V, 50mA

Mechanical and Environment

• Dimension: 50 x 40 x 25 mm
• Weight: 35g
• Temperature:
  • Operating: 0°C ~ 65°C (32°F ~ 149°F)
  • Storage: -20°C ~ 70°C (-4°F ~ 158°F)
• Humidity:
  • Operating: 10% ~ 95% non-condensing
  • Storage: 5% ~ 95% non-condensing

LED

• SYS (PWR)

Regulatory Approval

• FCC: Part15 Class A
• CE: EN55022 Class A, EN55024
• RoHS: Compliance

Warranty

• 1 Year
