Features

• Plug & Play installation
• Built in 15KV ESD protection for signals
• Windows, MAC OS, Linux driver support
• Compact and User friendly Design
• Type A USB Connecor

Specifications

Serial Interface

• Port number: 1
• Port Type: RS-232 x 1 Port ( DB9 )
• Connector: Male DB9
• RS-232 Speed: 300 bps ~ 921.6 Kbps
• Parity: None, Odd, Even, Mark, Space
• Data Bit: 5, 6, 7, 8
• Stop Bit: 1, 2
• RS-232: Rx, Tx, GND, RTS, CTS, DTR, DSR,
• Receive: buffer 576 Bytes
• Transmit: buffer 640 Bytes
• Flow Control: X-on / X-off or Hardware

Power

• Input: USB Bus power, DC5V, 50mA

Driver Support

• Windows 98SE/2000/XP/2003/VISTA/WIN 7/WIN 8
• MAC OS OSX / OS9
• Linux 2.4 / 2.6

USB Interface

• Chipset: Silicon Lab CP2102
• USB spec: USB 1.0, 1.1, 2.0
• Connector: USB Type B
• Baud Rates: Full speed 12Mbps

Environment

• Temperature:
  • Operating: 0°C ~ 65°C (32°F ~ 149°F)
  • Storage: -20°C ~ 70°C (-4°F ~ 158°F)
• Humidity:
  • Operating: 10% ~ 95% non-condensing
  • Storage: 5% ~ 95% non-condensing

Dimension & Weight

• Dimension: 55 x 40 x 25 mm
• Weight: 35g
• Regulatory Approval
• FCC: Part15 Class A
• CE: EN55022 Class A, EN55024
• RoHS: Compliance

Warranty

• 1 Year
