Dyno-Scan for Windows Bluetooth

Part No.: MPAUT-Dyno-Scan-for-Windows-Bluetooth
It's a full-featured On-Board Diagnostics (OBD II) scan tool capable of diagnosing a wide range of vehicle problems.


Dyno-Scan for Windows Bluetooth

Dyno-Scan is two products in one! First, it's a full-featured On-Board Diagnostics (OBD II) scan tool capable of diagnosing a wide range of vehicle problems. Second, the dyno package measures engine horsepower and torque, acceleration times, and even instantaneous and trip fuel mileage.

Android and Windows PC software is included for the Bluetooth OBD II adapter. The Dyno-Scan for Android app is a free download for your tablet or smartphone on Google Play

The A-303 Dyno-Scan works on all 1996 and newer vehicles and supports all OBD II communication protocols: CAN bus, VPW, PWM, ISO and KWP 2000.

The included Dyno-Scan for Windows software supports a PC with Windows XP/Vista/7/8/10. English, Spanish, German, Italian, French, Hungarian and Greek versions included. English and Metric units of measure.

Package Contents

The Dyno-Scan for Windows Bluetooth kit includes everything you need to wirelessly connect a PC to your vehicle.

  • Dyno-Scan for Windows Software (S-101)
  • OBD II Adapter (B-303)
  • OBD II Cable (O-102)
  • Quick Start

Key Features

  • All 1996 and newer vehicles supported, including American, Asian and European
  • Bluetooth OBD II adapter for wireless connection to a Windows PC or Android
  • Windows XP, Vista, 7, 8 and 10 Supported (32-bit and 64-bit, all versions)
  • Supports 264 live data parameters and multiple ECUs
  • English and Metric units of measure.
  • Turn off the vehicle's Check Engine or Service Engine Soon light
  • Read and clear diagnostic trouble codes (DTCs)
  • Integrated DTC description databases with thousands of code definitions, including enhanced and generic definitions
  • Supports diagnostic modes 1 through 9
  • Supports enhanced diagnostic modes 13, 14, 17, and 18
  • Rugged molded OBD II cable design
  • CAN, VPW, PWM, ISO and KWP 2000 protocols supported
  • High speed CAN 6x communication mode
  • Bi-directional control support
  • Read and clear freeze frame data
  • Monitor live data with line graphs, bar graphs, and meters
  • Graphically zoom in/out and pan within a virtual trace buffer
  • View multiple sensors simultaneously with variable sample rates
  • Record and playback live sensor data streams
  • Oxygen sensor monitoring and on-board test results
  • Measure vehicle gear ratio
  • I/M readiness. Metric and English units of measure
  • Printing and screen shot export to an image file
  • Horsepower and torque measurements
  • 0-60 time, 1/8 and 1/4 mile time and speed, MPG, and top speed
  • Spanish, German, French, Italian, Hungarian and Greek support
  • 1-year warranty


Size 3.5" W x 1.75" H x .875" D
Weight 4 oz
External Power None. Draws power from vehicle OBD II connector.
Temperature 32° to 158° F (0° to 70° C) non-condensing
OBD II Protocols J1850 (VPW, PWM), ISO 9141, ISO 14320 (KWP), and ISO 15765 (CAN bus) protocols
PC Connection Bluetooth wireless
