CAN, CAN-FD, LIN Kit

Part No.: MPWW-CAN-CAN-FD-LIN-Kit
A network analysis kit providing software and a 2 channel interface that can be connected to CAN CAN FD or LIN in any combination of these protocols.

產品介紹

X-Analyser CAN CAN FD LIN Kit

A network analysis kit providing software and a 2 channel interface that can be connected to CAN, CAN FD or LIN in any combination of these protocols. The kit contains:
  • X-Analyser Professional software with support for CAN (inc. CANopen/J1939/NMEA2000), CAN FD and LIN
  • Kvaser Hybrid interface – connects PC via USB to 2 channels of CAN, CAN FD or LIN
  • Carrying case

WCT Kit Bag

Neoprene bag for carrying your portable tech

Kvaser Hybrid 2xCAN/LIN

Kvaser Hybrid 2xCAN/LIN is a flexible, dual channel interface that allows each channel to be assigned independently as
CAN or LIN. This makes the Kvaser Hybrid 2xCAN/LIN a must-have ’universal interface’ for every engineer involved in
automotive communications.
With a standard USB connector and two CAN/LIN channels in two separate 9-pin D-SUB connectors, this interface can
connect a PC to two CAN buses, two LIN buses, or one CAN and one LIN bus.

X-Analyser 3 Professional (Multiple Channel)

This has all the features of the Standard with addition of interpretation of standard Higher Layer Protocols - J1939, NMEA2000 and CANopen. Comes with J1939 and NMEA2000 CAN data bases (dbc). The Professional is Multiple Channels (CAN and/or LIN) – dongled from 1 Kvaser interface serial number, any number of other interfaces can be connected.
