Xeltek Fiber Laser Marking Machine
SPECIFICATIONS
|
Max. Laser Power |
10W |
|---|---|
|
Laser Wavelength |
1064nm |
|
Beam Quality |
M2<1.8 |
|
Pulse Width |
90 ~ 120us |
|
Single Pulse Energy |
1mJ / 20KHZ |
|
Min. Line Width |
0.01mm |
|
Min. Character Height |
0.2mm |
|
Repeat Accuracy |
0.002mm |
|
Marking Speed |
≤10000mm/s |
|
Marking Range |
100mm*100mm (Standard) Optional for others |
|
Cooling |
Air cooling |
|
Power Supply |
AC220V/50HZ |
|
Power Consumption |
500W |
Features
-
Durable for Long Production Hours: The fiber laser marking machine suitable for continuous operation during production.
-
Wide application: Ability to mark both metal and nonmetallic materials, such as plastic, rubber, resin, acrylic, paper, fabric, and leather.
-
High marking precision: The minimum marking line width is 0.01mm, suitable for modern compact IC devices.
-
Energy savings reduce production cost: The entire machine only consumes 500 Watt Per Hour.
-
High marking speed: Marking speed as fast as 10,000 mm/sec.
-
Minimal maintenance: The XLM-04 fiber laser system is simply maintenance-free. Only some wearing parts, such as the lens, require replacement.
-
Compact: The system has smaller dimensions because it utilizes a modern air-cooling method instead of the traditional air conditioner.
-
Powerful computer system and software: Powerful and user-friendly hardware and software interface.
