This series of products allows to integrate a SNMP network with a KNX net.
The HD67820 is a SNMP / KNX Converter and it allows you to connect a SNMP net (for example a Supervisory System…) with a KNX net (for example light switches, actuators…) in order to exchange the informations between the networks.
This converters are very easy to configure and allows you to interface a SNMP system with the KNX world.
On KNX side you can connect all the common KNX devices such as temperature sensors, shutters, light switches, actuators, alarms etc.
SNMP / KNX - Converter ( Ethernet Switch Inside for enter/exit connection, Housing type: B, Terminal Blocks Connectors )
|KNX Protocol||KNX TP|
|SNMP Protocol||SNMP slave|
|Data Rates KNX||9600 bit/s|
|Data Rates Ethernet||10/100 Base-T Autosensing|
|KNX Connector||KNX Bus connector|
|Power Supply||8..24V AC; 12..35V DC|
|Power Supply Connector||2way 5mm terminal block|
|Operating Temperature||-40° to +85° (-40°F to +185°F)|
|Mechanical Fixing||35mm DIN Rail montage|
|AC34011||Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC|
|AC34012||Isolated Converter 100..240V AC to 24V DC stabilized - AC/DC|
|AC34-AB1TP||KNX Power Supply - KNX out 640mA - in 240VAC|
|AC34-AG1TP||KNX Power Supply - KNX out 640mA + AUX out 30VDC - in 240VAC|
