IEC 61850 to MQTT
Part No.: MPADFW-IEC-61850-to-MQTT
This series of products allows to integrate some IEC61850 devices into a MQTT network.
產品介紹
IEC 61850 / MQTT - Converter
This series of products allows to integrate some IEC61850 devices into a MQTT network.
The HD67747-B2 is an IEC 61850 Server / MQTT Converter so you can connect an IEC 61850 Client network (for example a SCADA, HMI etc..) with a MQTT net in order to exchange informations between the nets.
The HD67774-B2 is an IEC 61850 Client / MQTT Converter so you can connect an IEC 61850 Server network (for example a Meters, Switces etc..) with a MQTT net in order to exchange informations between the networks.
IEC 61850 / MQTT
HD67747-B2
IEC 61850 Server / MQTT - Converter ( Housing type:B, Terminal Blocks Connectors )
| Ports | 1xEthernet | |
|---|---|---|
|
Ethernet Protocol
|
MQTT | |
| IEC 61850 Protocol | Server | |
| Data Rates MQTT | 10/100 Base-T Autosensing | |
| Data Rates IEC 61850 | 10/100 Base-T Autosensing | |
| MQTT Connector | RJ45 | |
| IEC 61850 Connector | RJ45 | |
| Power Supply | 8..24V AC; 12..35V DC | |
| Power Supply Connector | 2way 5mm terminal block | |
| Operating Temperature | -40° to +85° (-40°F to +185°F) | |
| Dimensions | 36x60x95 (DxWxH) | |
| Weight | 200g approx | |
| Mechanical Fixing | 35mm DIN Rail montage | |
| Software | SW67747 | |
HD67774-B2
IEC 61850 Client / MQTT - Converter ( Housing type:B, Terminal Blocks Connectors )
| Ports | 1xEthernet | |
|---|---|---|
| Ethernet Protocol | MQTT | |
| IEC 61850 Protocol | Client | |
| Data Rates MQTT | 10/100 Base-T Autosensing | |
| Data Rates IEC 61850 | 10/100 Base-T Autosensing | |
| MQTT Connector | RJ45 | |
| IEC 61850 Connector | RJ45 | |
| Power Supply | 8..24V AC; 12..35V DC | |
| Power Supply Connector | 2way 5mm terminal block | |
| Operating Temperature | -40° to +85° (-40°F to +185°F) | |
| Dimensions | 36x60x95 (DxWxH) | |
| Weight | 200g approx | |
| Mechanical Fixing | 35mm DIN Rail montage | |
| Software | SW67774 | |
Accessories
| Order Code | Description |
|---|---|
| AC34011 | Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC |
| AC34012 | Isolated Converter 100..240V AC to 24V DC stabilized - AC/DC |
| AC34131 | Patch Cross Cable Cat6 2 Meters |
