DeviceNet to Modbus TCP

Part No.: MPADFW-DeviceNet-to-Modbus-TCP
This series of products allows to integrate a DeviceNet network with a Modbus net.

產品介紹

DeviceNet / Modbus TCP - Converter

This series of products allows to integrate a DeviceNet network with a Modbus net.

The HD67139 is a DeviceNet Slave / Modbus TCP Master Converter and it allows you to connect a DeviceNet Master net (for example an ABB PLC...) with some Modbus devices.

The HD67140 is a DeviceNet Slave / Modbus TCP Slave Converter and it allows you to connect a DeviceNet Master net (for example an ABB PLC...) with a Modbus TCP Master (for example a PLC, SCADA System...).

The HD67152 is a DeviceNet Master / Modbus TCP Slave Converter and it allows you to connect some DeviceNet slaves with a Modbus TCP Master (for example a PLC, SCADA System...).


Series Modbus TCP Master from/to DeviceNet Slave



HD67139-A1

DeviceNet Slave / Modbus TCP Master - Converter ( Housing type: A, Terminal Blocks Connectors )





Ports 1xEthernet; 1xDeviceNet
Modbus TCP Connector RJ45
Power Supply Connector Terminal Block
Power Supply 8...19V AC ; 8...35V DC
Operating Temperature -40ºC/+85ºC (-40ºF/+185ºF)
Dimensions 120x23x107 mm(DxWxH)
Weight 200g approx
Mechanical Fixing DIN Rail montage
Software SW67139



HD67139-B2

DeviceNet Slave / Modbus TCP Master - Converter ( Housing type: B, Terminal Blocks Connectors )





Ports 1xEthernet; 1xDeviceNet
Modbus TCP Connector RJ45
Power supply Connector Terminal Block
Power Supply 8...19V AC ; 8...35V DC
Operating Temperature -40ºC/+85ºC (-40ºF/+185ºF)
Dimensions 71x60x95 mm(DxWxH)
Weight 200g approx
Mechanical Fixing DIN Rail montage
Software SW67139

Series Modbus TCP Server from/to DeviceNet Slave



HD67140-A1

DeviceNet Slave / Modbus TCP Master - Converter ( Housing type: A, Terminal Blocks Connectors )





Ports 1xRS232; 1xEthernet; 1xDeviceNet
Modbus TCP Connector RJ45
Power Supply Connector Terminal Block
Power Supply 8...19V AC ; 8...35V DC
Operating Temperature -40ºC/+85ºC (-40ºF/+185ºF)
Dimensions 120x23x107 mm(DxWxH)
Weight 200g approx
Mechanical Fixing DIN Rail montage
Software SW67140



HD67140-B2

DeviceNet Slave / Modbus TCP Slave - Converter ( Housing type: B, Terminal Blocks Connectors )





Ports 1xRS232; 1xEthernet; 1xDeviceNet
Modbus TCP Connector RJ45
Power supply Connector Terminal Block
Power Supply 8...19V AC ; 8...35V DC
Operating Temperature -40ºC/+85ºC (-40ºF/+185ºF)
Dimensions 71x60x95 mm(DxWxH)
Weight 200g approx
Mechanical Fixing DIN Rail montage
Software SW67140

Series Modbus TCP Server from/to DeviceNet Master



HD67152-A1

DeviceNet Master / Modbus TCP Slave - Converter ( Housing type: A, Terminal Blocks Connectors )





Ports 1xEthernet; 1xDeviceNet
Modbus TCP Connector RJ45
Power Supply Connector Terminal Block
Power Supply 8...19V AC ; 8...35V DC
Operating Temperature -40ºC/+85ºC (-40ºF/+185ºF)
Dimensions 120x23x107 mm(DxWxH)
Weight 200g approx
Mechanical Fixing DIN Rail montage
Software SW67152



HD67152-B2

DeviceNet Master / Modbus TCP Slave - Converter ( Housing type: B, Terminal Blocks Connectors )





Ports 1xEthernet; 1xDeviceNet
Modbus TCP Connector RJ45
Power supply Connector Terminal Block
Power Supply 8...19V AC ; 8...35V DC
Operating Temperature -40ºC/+85ºC (-40ºF/+185ºF)
Dimensions 71x60x95 mm(DxWxH)
Weight 200g approx
Mechanical Fixing DIN Rail montage
Software SW67152





Accessories


Order Code Description
AC34011 Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC
AC34012 Isolated Converter 100..240V AC to 24V DC stabilized - AC/DC
AC34107 Null Modem Cable, Fem/Fem, DSub 9 Pin, 1.8 m
AC34114 Null Modem Cable, Fem/Fem, DSub 9 Pin, 5 m

Benefits

  • Software for easy configurator
  • Designed for serius use
  • Very easy to configure
  • Low cost
  • Rail din mountable
  • Wide supply input range
  • Galvanic isolation
  • Industrial temperature range:  -30°C / 70°C (-22°F / 158°F)
