Part No.: MPEM-Micro-CANopen-Source-Code-Plus-Licence
Drivers included are for NXP LPC ARM Cortex devices and the CANoepn Magic simuöation system.
Our Micro CANopen Plus sour code implements the most often used functions of the CANopen protcol stack. Drivers included are for NXP LPC ARM Cortex devices and the CANoepn Magic simuöation system.
MicroCANopen Plus is a small-footprint, commercial-grade CANopen implementation with advanced features. Ideal for situations requiring medium configurability during run-time and great performance on any type of platform, and for building networks that include manager nodes, MicroCANopen Plus provides the most flexible solution. Auto-generated configuration from the EDS/DCF file makes its setup a quick and painless one-step process.
Portable. MicroCANopen Plus is written in 100% standard ANSI C code allowing for straightforward porting. For targets without standard support packages, designers familiar with their target processor can easily perform the port themselves. Or, ask us for a quote to add support to your target!
Compact. ROM Specifications: 7K - 14K bytes (for CANopen Slaves) depending upon processor and options selected.
An Affordable Pricing Structure. MicroCANopen Plus offers a low, one-time fee and no royalties on deployed products and includes all source code with every purchase.
The following is a non-exhaustive overview of features in Micro CANopen Plus:
The following platforms are supported by Micro CANopen Plus:
Non-embedded:
Other embedded microcontrollers:
MicroCANopen Plus is delivered with an example CiA401 (Generic I/O) implementation and drivers for NXP LPC ARM and CANopen Magic Ultimate simulation.
Customized examples for other device profiles are available under our consulting services.
Our stack passes the official CANopen Conformance Test!
Full documentation is supplied. All software products include a one-year maintenance and priority support agreement that can be extended anytime.
Also included is a single licence for CANopenArchitectEDS, an EDS/DCF editor with code generation for quick stack configuration.
